Video communication with Pylontech battery
The New Hybrid Inverter 5000W 48V Voltronic Axpert VMIII is a very versatile all-in-one device. It is intended for use in isolated installations to work on 48V batteries. It offers up to 5000W of power output and allows us to connect panels to work in a hybrid way. This Hybrid Inverter 5000W 48V Voltronic axpert VMIII can work with a photovoltaic field of high voltage equal to the investors network connection . This simplifies connection, increases efficiency and reduces high current losses. Thanks to this, you can connect up to 5000W with solar panels .
- Pure Sine Wave Solar Inverter
- High voltage range at PV input
- Inverter can operate without battery bank
- Built-in 80A MPPT Solar Charger
- Battery bank equalization function to optimize performance and extend life cycle
- Maximum power of solar panels 5000w
- Wifi Plus function
- BMS For batteries Built-in
- Bluetooth function
Hybrid Inverter 5000W 48V Voltronic Axpert VMIII. It is a further step in the range of domestic models from Voltronic's Axpert range thanks to integrating a charger inverter together with a regulator prepared to work at high panel voltage. It offers up to 5000W of output power, supports up to 5000W to connect panels, work with or without batteries of any type at 48V and be able to have bluetooth connectivity to monitor from our smartphone
With the hybrid inverters of the VM2 and VM3 series it is advisable to use an AC stabilizer for use with a generator set.
Features of the Hybrid Inverter 5000W 48V Voltronic Axpert VMIII
The Hybrid Inverter 5000W 48V Voltronic Axpert VMIII offers a series of interesting features compared to its competition, such as the following:
- Removable screen with the possibility of remote use (with cable). The LCD screen can be detached to have control and display of the parameters of our investor up to a maximum cabling distance of 20 meters.
- Integrated Bluetooth. We can view the inverter parameters from a maximum distance of 7 meters via the WatchPower app on our smartphone with Android system and wirelessly.
- Communications port for BMS. It has a communications port that supports the RS-485, CAN-BUS and RS-232 protocols to be able to communicate lithium batteries that incorporate your BMS and thus the inverter has the energy readings provided by the battery.
- Battery equalization. To extend the useful life of lead acid batteries, this functionality allows to eliminate the sulphation that is generated in the plates of this type of accumulators, whether they are monobloc of open lead acid batteries or stationary batteries OpzS.
- Possibility of operation without battery. Through this functionality, the inverter can be connected to the panels and the incoming electrical grid and directly to the consumptions without the need for a connected battery. The consumptions connected to the inverter will be fed directly from the two external sources connected without the need for a battery to be present.
- Easy repairability of the ventilation. Since most physical problems can arise from faults in the ventilation system, the possibility of replacing the fans without having to disassemble the unit for easier maintenance is facilitated.
5KW Inverter Installation VM III 48v hybrid
In order to provide maximum protection for both the inverter and the system in general, we advise you to put a Protection and Pre-installation Kit. Installation of this 5KW Inverter model 48v hybrid is simple with your pre-installation kit, however in Wccsolar you We recommend that the 5KW VM III 48v Hybrid Inverter be installed by a photovoltaic professional, or the installation instructions are strictly followed to avoid bad connections and breakdowns due to incorrect installation.
Buy Inverter 5KW VM III 48v hybrid
Buy the Inverter 5KW VM III 48v hybrid is fast, safe and comfortable thanks to Wccsolar, plus the 5KW VM III 48v hybrid inverter It has an official guarantee from Wccsolar.
Contact us to receive more information.
2 years warranty
Hybrid Inverter 5KW 48v Mppt 80A / 500V VM III
Data sheet
-Model: 5KW VM III 48v
- Nominal power: 5000W.
- Input voltage: 48V.
- Selectable voltage range: 170-280 VAC (for computers) 90-280 VAC (for home appliances).
- Frequency range: 50Hz / 60Hz (automatic detection).
- Output voltage regulation (battery mode): 230 VAC + -5%
- Maximum power (starting peaks): 10000W.
- Efficiency: 90-93%.
- Transfer time: 10 ms (for computers) 20 ms (for household appliances).
- Wave type: Pure sine wave.- Maximum voltage of the photovoltaic panel open circuit 500VDC
- Battery voltage: 48V.
- Float charge voltage: 54V.
- Overload protection: 63V.
- MPPT regulator charging current: 80A.
- Charger charging current: 60A.
- Power consumption in stand-by: 10W.- Measurements: 100 x 300 x 440 mm
- Weight: 12Kg.Characteristics
Savings in the Inverter charger 5000VA 48V WccSolar
The 5000VA 48V inverter charger includes -among other things - a 48V volt 80A solar battery charging controller and a 230VAC charger.If the house consumption is higher than the energy produced by the batteries alone, it will use all the energy solar and will take the missing electricity from the power grid.
The 5000VA 48V inverter charger is fully programmable, the possibility of connecting an external generator ensures that you will never be without electricity.
The speed of connecting between the grid, solar panels or batteries is so fast that absolutely nothing is perceived; you will always have a smooth supply of electrical power without interruptions.
The LCD screen has a resolution of 255 x 160 pixels with backlight making it easy to read. The energy generation data, alerts and other information are displayed to the user clearly and easily.
Inverter Charger 5000VA 48V WccSolar It is an all-in-one system that does not need any more devices.
Inverter Charger 5000VA 48V WccSolar You always prefer power from the sun or batteries and as a last resort you will use power from the electricity grid or the generator set, so you will be independent from your power company.
Inverter Easy to install
There is no other system as easy to install as the WccSolar 5000VA 48V Inverter Charger series. This is not only good for the person who performs the installation - you will also save time, space and money.
Inverter configuration
Remote control and programming software included (WATCHPOWER) and inverter-computer USB cable. WatchPower includes monitoring application and inverter configuration application. It allows the control and surveillance of various devices through the AN, Internet or USB. Warning or alarm notifications via audible alarm, pop-up screen, transmission, SMS, inbox message and email. Download the latest version from the web:
Cautions
With the hybrid inverters of the VM2 and VM3 series it is advisable to use an AC stabilizer for use with a generator set.
