AC connectors for SUN Microinverter 600W, 1300W, 2000W
Higher yields / Safe / Smart / Easy to use
This connectors is worth for models the SUN 600W 1300W 2000W-G3 DEYE is used _CC781905-5CDE-3194-BB3B-13BAD5CF58D_ to connect the terminals of_CC781905-5CDE-3194-BB3B-36BAD5CF58D_INVERSOR TO THE HOUSE
About the AC conntor:
Shell: The main body is made of imported materials such as PPO/PC, nylon and silicone rubber, which has strong anti-aging and ultraviolet resistance.
Metal Terminal: Copper Alloy + Silver Plated on the surfaceProtection level: IP68
Certification qualification: TUV, CSA, CQC three certifications, global smooth
Number of electrode cores | 2P + PE |
current rate | 25A |
voltage rate | CSA:250/350V AC; TUV:250V AC |
contact resistance | ≤ Lmq |
Power Frequency Support Voltage | 4000V AC |
surge type | II |
contamination level | two |
protection level closed | IP68 (1.5m, 24h) |
fire retardant grade | UL94-V0 |
Insertion and extraction force | 10 ~ 50N (without lock) |
Applicable ambient temperature | -40 ~ 85 degree |
standard grade | |
EN 61535 and PPP 59015A:2013 | IEC and VDE-Photovoltaic Connector Safety Test Standards |
UL .6703A | USA, Canada - Safety Test Standards for Photovoltaic Connectors |
Manual Microinverter 600w 1300w 2000w PlusEnergy
Technical sheet Microinverter 2000w PlusEnergy
Microinverter Connector
Data sheet
Number of electrode cores
2P + PE
current rate
25A
voltage rate
CSA:250/350V AC; TUV:250V AC
contact resistance
≤ Lmq
Power Frequency Support Voltage
4000V AC
surge type
II
contamination level
two
protection level closed
IP68 (1.5m, 24h)
fire retardant grade
UL94-V0
Insertion and extraction force
10 ~ 50N (without lock)
Applicable ambient temperature
-40 ~ 85 degree
standard grade
EN 61535 and PPP 59015A:2013
IEC and VDE-Photovoltaic Connector Safety Test Standards
UL .6703A
USA, Canada - Safety Test Standards for Photovoltaic Connectors
Characteristic
Grid connection standard
EN50549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116,RD1699, UNE 206006 EN, UNE 206007-1 EN, IEEE1547
EMC Safety / Standard
UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
