Polycrystalline Solar Panel 12V 160W 36 Cells
160W Polycrystalline 12 Volt Solar Panel It is one of the most powerful in the 12-volt range, thanks to 5 buses each cell to produce maximum solar efficiency.
Widely used for installations in 12-volt kits , in country houses , chalets and houses of habitual use incorporating with it, batteries and charge regulators.
It is made up of polycrystalline silicon , more efficient than monocrystalline in hot weather and at a lower price, which is why this panel offers optimal performance guarantees at a very competitive price.
It is a 12V solar panel and therefore 36 cells . Its technology makes it even more efficient by capturing a higher production of the same in all possible solar conditions.
Solar Module 12V 160W polycrystalline 36 Cells
In Wccsolar you can purchase the Solar panel 160W polycrystalline 12 volts as the only component, although for those cases where what you want is to make a photovoltaic installation To have energy autonomy and opt for solar self-consumption , we recommend the isolated connection solar kits that are an excellent option when the electrical network does not reach where it is desired, so this type of kits They provide absolute autonomy and independence from electricity companies, providing energy during daylight hours that will be consumed and stored so that it can also be consumed at night or when solar energy is not available due to weather conditions.
On the other hand, if you want to reduce the electricity bill of your electricity company by using the services of the electricity company during the night hours or when photovoltaic energy is not available due to weather conditions, we recommend the following: solar grid connection kits .
Both of them solar kits can be completely customizable according to your needs, and you can see how many of them include the Solar panel 160w polycrystalline 12 volts a more attractive price than buying it separately.
Solar Panel 12V 160W Polycrystalline
Data sheet
- Nominal power Pmax: 160 WP
- Nominal voltage U MPP: 17.46 V
- Nominal current IMPP: 9.17 A
- Open circuit voltage U0: 21.42 V
- Short circuit current ISC: 9.81 TO
- Module Efficiency: 15.89%
- Dimensions: L x W 1480 x 680 x 35 mm
- Frame box Height / with: 35mm / 35mm
- Weight: 12 Kg
- Module connectivity: 950mm with MC4 connector
- Frame Color: Anodized Silver
Performance
- High module conversion efficiency up to 18.52% by using high-efficiency solar cells
- and advanced manufacturing technology.
- Low degradation and excellent performance under high temperatures and low light
- terms
- The robust aluminum frame ensures that the modules withstand wind loads of up to 2400 Pa
- and snow loads up to 5400 Pa.
- High reliability against extreme environmental conditions (passing salt mist,
- ammonia and hail tests).
- Possible resistance to induced degradation (PID).
- 0 ~ + 3% positive power tolerance.
Certifications
- IEC61215, IEC61730, IEC62716, IEC61701, CE, CQC, CGC, ETL (USA),
- JET (Japan), J-PEC (Japan), Kemco (South Korea), KS (South Korea), MCS (United Kingdom),
- CEC (Australia), FSEC (FL-USA), Eligible CSI (CA-USA), Israel Electric (Israel),
- InMetro (Brazil), TSE (Turkey)
- ISO9001: 2008: quality management system
- ISO14001: 2004: environmental management system
- OHSAS18001: 2007: Occupational Health and Safety Management System
